1500kVA Three Phase Dry Type Power Transformer Step Down Transformer 11kV to 415V
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Type Distribution Transformer, Power Transformer Input Voltage 3 kV Output Voltage 220 V, 415V Frequency 50 Hz, 60 Hz Phase Three Coil Number 2 Winding Material Aluminum, Copper Material Aluminum, Copper application Power, Industrial Control, Distribution Toplogy Three-phase Core-type Coil Structure Vacuum Cast Epoxy Resin Coil Shape Rectangle, Round Rated Capacity 30kVA-40000kVA (Customizable) Rated Voltage […]
Introduction
| Type | Distribution Transformer, Power Transformer | Input Voltage | 3 kV |
| Output Voltage | 220 V, 415V | Frequency | 50 Hz, 60 Hz |
| Phase | Three | Coil Number | 2 |
| Winding Material | Aluminum, Copper | Material | Aluminum, Copper |
| application | Power, Industrial Control, Distribution | Toplogy | Three-phase Core-type |
| Coil Structure | Vacuum Cast Epoxy Resin Coil | Shape | Rectangle, Round |
| Rated Capacity | 30kVA-40000kVA (Customizable) | Rated Voltage | HV:6/10/11/13.8/20/33/35kV LV:0.4/0.38/0.415/0.48kV(Customizable) |
| Winding Type | Foil Winding (LV) / Layer Winding (HV) | Insulation Class | Class F / Class H (High Temp Resistance) |
| Design Standard | IEC 60076/ IEEE / ANSI / CE / ISO | Enclosure Rating | IP20 / IP23 / IP44 / IP54 (With/Without Enclosure) |
| Vector Group | Dyn11 / Dyn5 / Yyn0 / Yd11 (Customizable) | Short-circuit Impedance | 4.0% / 6.0% / 8.0% (Optional) |
| Core Material | High Permeability CRGO / Amorphous Alloy |
Our website currently displays only a selection of our transformer products. If you are looking for specific models or need detailed technical information, please feel free to contact us. As a professional transformer supplier, China Loong Transformer Co., Ltd. is committed to providing tailored solutions to meet various application needs. Whether you require oil immersed transformers, dry type transformers, special transformers, or compact substations, our experienced team is ready to assist with product selection, customization, and technical support. Let’s work together to deliver reliable and efficient power solutions that drive your business forward.
