50 kVA Single Phase Pad Mounted Transformer 12.47kV 7.2kV to 240 120V ANSI C57.12.38 for Residential Underground Distribution
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Input Voltage 12.47 kV, 13.2 kV, 7.2 kV, 7.62 kV Output Voltage 240V 120V Frequency 60 Hz Phase Single Type Oil-Immersed Transformer Coil Number Two Windings Coil Structure Layer Coil Application Distribution System Standard Compliance ANSI / IEEE C57.12.38 Polarity Additive / Subtractive Efficiency Standard DOE 2016 Compliant Winding Material 99.9% Pure Copper (Cu) Insulating […]
Introduction
| Input Voltage | 12.47 kV, 13.2 kV, 7.2 kV, 7.62 kV | Output Voltage | 240V 120V |
| Frequency | 60 Hz | Phase | Single |
| Type | Oil-Immersed Transformer | Coil Number | Two Windings |
| Coil Structure | Layer Coil | Application | Distribution System |
| Standard Compliance | ANSI / IEEE C57.12.38 | Polarity | Additive / Subtractive |
| Efficiency Standard | DOE 2016 Compliant | Winding Material | 99.9% Pure Copper (Cu) |
| Insulating Liquid | Mineral Oil (Non-PCB) | Primary Configuration | Dead Front |
| BIL (Impulse Level) | 95 kV | Enclosure Standard | ANSI C57.12.28 |
Our website currently displays only a selection of our transformer products. If you are looking for specific models or need detailed technical information, please feel free to contact us. As a professional transformer supplier, China Loong Transformer Co., Ltd. is committed to providing tailored solutions to meet various application needs. Whether you require oil immersed transformers, dry type transformers, special transformers, or compact substations, our experienced team is ready to assist with product selection, customization, and technical support. Let’s work together to deliver reliable and efficient power solutions that drive your business forward.
