Customized Service EMI Shielding Flat Wire Inductor for High Performance Audio Speaker
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Type Edgewise Winding / Flat-wise Winding Inductor Mounting Type Bolt-on / Custom Solder Leads Function HF Filtering / Resonance / Energy Storage Supplier Type Manufacturer Direct Supply Q @ Freq High Q-factor: > 80 Application High-power Inverters / EV Charging Piles Rated Power 100W – 5000W (Size dependent) Mfg. Date Code 20260101-20561230 Cross Reference Custom-made […]
Introduction
| Type | Edgewise Winding / Flat-wise Winding Inductor | Mounting Type | Bolt-on / Custom Solder Leads |
| Function | HF Filtering / Resonance / Energy Storage | Supplier Type | Manufacturer Direct Supply |
| Q @ Freq | High Q-factor: > 80 | Application | High-power Inverters / EV Charging Piles |
| Rated Power | 100W - 5000W (Size dependent) | Mfg. Date Code | 20260101-20561230 |
| Cross Reference | Custom-made Parts | Tolerance | Inductance Tolerance ±5% or ±10% |
| Operating Temperature | -40℃ to +180℃ (Class H) | Package Type | Open-frame Custom Packaging |
| Resistance Tolerance | Resistance Error ±5% | Temperature Coefficient | 3930 ppm/K (Pure Copper) |
| Resistance | 0.2mΩ - 5.0mΩ(DCR) / Frequency Dependent | Media Available | Datasheet / Drawings / RoHS |
| Frequency - Self Resonant | Self-resonant Frequency (SRF) > 1 MHz | Features | High Current/ Ultra-low DCR/ High Heat Dissipation |
| Height - Seated (max) | Customized / 10-50mm (Turns dependent) | Inductance | Customized / 1μH - 100μH |
| Package / Case | Bare Coil / Varnish Impregnated | Size / Dimension | Outer Diameter: 20mm - 120mm |
| Heigh | Customized / 5mm - 100mm | Number of Coils | Customized / 3T - 200T |
| Inductance - Connected In Parallel | Customized / 1μH - 100μH | Inductance - Connected In Series | Customized / 1μH - 100μH |
| Current Rating - Parallel | Customized / 20A - 200A | Current Saturation - Parallel | No Saturation (Air core does not saturate) |
| Current Saturation - Series | No Saturation (Air core does not saturate) | DC Resistance (DCR) - Parallel | 0.2mΩ - 5.0mΩ |
| DC Resistance (DCR) - Series | 0.2mΩ - 5.0mΩ | Shielding | Non-shielded |
| Material - Core | None / Ferrite / Mn-Zn / Ni-Zn / Sendust (Kool Mu) | Current Rating (amps) | 20A - 200A |
| Current - Saturation | 20A - 200A | DC Resistance (DCR) | 0.2mΩ - 5.0mΩ |
| Mounting Technology Type | Surface Mount and Through Hole PCB Design | Terminal and Lead Format | Radial Leaded and DIP Connection for Power Supply |
| Magnetic Shielding Options | Shielded and Unshielded Inductor Core Construction | Custom Shielding Service | Provide Customized Shielding for EMI Interference Suppression |
| Electronic Application Scope | Transmitter Application and For Receiver Circuits | Standard Compliance Status | CE Certified and RoHS Compliant Green Materials |
| France EPR Packing Standard | EPR France Packing Certified for International Sales | German EPR Packing Standard | German EPR Packaging for European Market Distribution |
| Professional Packaging Option | Customized Packing for Safe Logistics Delivery | SMT and DIP Assembly Types | High Density Surface Mount and DIP Inductor Unit |
