KDZRS 20A Micro Ohmmeter Class Digital Transformer Resistance Tester for Detecting Winding Deformations and Faults in HV Labs
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Measuring Range 500μΩ~500mΩ,10mΩ~1.0Ω,100mΩ~5.0Ω,1Ω~50Ω Accuracy Class TBD Testing Voltage 20A, 10A, 2A, 0.2A Operating Temperature -10 ℃~50 ℃ Time Resolution None Current Range 0-20 A Current Resolution 0.0001μΩ Display Type Digital Only Insulation Resistance None Dimensions 420mm x 250mm x 340mm(16.54inx9.84inx13.39in) Product name Transformer DC Resistance Tester Three phase test current 20A, 10A, 2A, 0.2A Single […]
Introduction
| Measuring Range | 500μΩ~500mΩ,10mΩ~1.0Ω,100mΩ~5.0Ω,1Ω~50Ω | Accuracy Class | TBD |
| Testing Voltage | 20A, 10A, 2A, 0.2A | Operating Temperature | -10 ℃~50 ℃ |
| Time Resolution | None | Current Range | 0-20 A |
| Current Resolution | 0.0001μΩ | Display Type | Digital Only |
| Insulation Resistance | None | Dimensions | 420mm x 250mm x 340mm(16.54inx9.84inx13.39in) |
| Product name | Transformer DC Resistance Tester | Three phase test current | 20A, 10A, 2A, 0.2A |
| Single phase test current | 20A, 10A, 5A, 1A, 0.1A | Three phase testing scope | 500μΩ~500mΩ,10mΩ~1.0Ω,100mΩ~5.0Ω,1Ω~50Ω |
| Single phase testing scope | 250μΩ~1.0Ω,2mΩ~2.0Ω,50mΩ~4.0Ω,100mΩ~20Ω,1Ω~200Ω | Resolution | 0.0001 μΩ, 5 significant digits |
| Host size | 420mm x 250mm x 340mm | Host weight | 15kg |
| Environmental temperature | -10 ℃~50 ℃ | Environmental humidity | 85% RH, non condensing |
Our website currently displays only a selection of our transformer products. If you are looking for specific models or need detailed technical information, please feel free to contact us. As a professional transformer supplier, China Loong Transformer Co., Ltd. is committed to providing tailored solutions to meet various application needs. Whether you require oil immersed transformers, dry type transformers, special transformers, or compact substations, our experienced team is ready to assist with product selection, customization, and technical support. Let’s work together to deliver reliable and efficient power solutions that drive your business forward.
