Pad Mounted Transformer American Type Box Substation 250kVA 500kVA 1000kVA for Power Distribution
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Rated Voltage 24 kV, 11 kV, 10 kV, 13.8KV Rated Current 630 A, 1250 A, 1600 A, 3150 A, 2500 A, 2000 A Frequency 50 Hz, 60 Hz Application Outdoor IP Level IP53 Material Aluminium Zinc Coated Plate, Stainless Steel, Steel Size 3500mm*1500mm*2200mm(137.80in*59.06in*86.61in) Power-frequency Withstand Voltage HV 42kV1min LV 5kV1min Rated Capacity(Dry Type) 302000kVA Seismic […]
Introduction
| Rated Voltage | 24 kV, 11 kV, 10 kV, 13.8KV | Rated Current | 630 A, 1250 A, 1600 A, 3150 A, 2500 A, 2000 A |
| Frequency | 50 Hz, 60 Hz | Application | Outdoor |
| IP Level | IP53 | Material | Aluminium Zinc Coated Plate, Stainless Steel, Steel |
| Size | 3500mm*1500mm*2200mm(137.80in*59.06in*86.61in) | Power-frequency Withstand Voltage | HV 42kV1min LV 5kV1min |
| Rated Capacity(Dry Type) | 302000kVA | Seismic Resistance Grade | Grade 7 Standard |
| Short-time Withstand Current | 16kA2s 20kA2s 25kA3s | Rated Capacity(Oil-immersed Type) | 502500kVA |
| Lightning Impulse Withstand Voltage | To EarthPhases 75kV 95kV Isolation 85kV 110kV | Altitude | ≤ 1000m |
| Connection Group | Dyn11 Mainstream Yyn0 | Peak Withstand Current | 40kA 50kA 63kA |
Our website currently displays only a selection of our transformer products. If you are looking for specific models or need detailed technical information, please feel free to contact us. As a professional transformer supplier, China Loong Transformer Co., Ltd. is committed to providing tailored solutions to meet various application needs. Whether you require oil immersed transformers, dry type transformers, special transformers, or compact substations, our experienced team is ready to assist with product selection, customization, and technical support. Let’s work together to deliver reliable and efficient power solutions that drive your business forward.
