SCT006 SCT006L 6mm Split Core Current Transformer 0.5% Accuracy TVS Protection for Power Meter EV Charger Energy Monitoring
Our website showcases only a selection of our products. If you have other requirements or can't find the right product, please feel free to contact our customer service team. We are here to assist you!
Type Current Transformer Sensitivity Defined by turns ratio Output Current output Number of channels 1 Communication Interface None Material Ferrite Core Theory Electromagnetic induction Usage AC current detection, Power monitoring Mounting Type Free hanging (In-Line) Manufacturer Part Number SCT006 / SCT006L Current – Sensing 1A, 5A, 10A, 20A (Rated input) Description Split-core current transformer series […]
Introduction
| Type | Current Transformer | Sensitivity | Defined by turns ratio |
| Output | Current output | Number of channels | 1 |
| Communication Interface | None | Material | Ferrite Core |
| Theory | Electromagnetic induction | Usage | AC current detection, Power monitoring |
| Mounting Type | Free hanging (In-Line) | Manufacturer Part Number | SCT006 / SCT006L |
| Current - Sensing | 1A, 5A, 10A, 20A (Rated input) | Description | Split-core current transformer series |
| Series | Split Core Current Transformer Series | Features | Safety lock buckle, Easy installation |
| Description | Split Core Current Transformer | Frequency | 50 - 1000 Hz |
| Accuracy | ±0.5% or ±1% | Voltage - Supply | Passive (Self-powered) |
| Linearity | High linearity (≤0.5% linearity error) | Bore Size | 6mm (for cable diameter up to 5.5mm) |
| Protection Class | IP00 | Output Ratio Options | 2.5mA/5mA/10mA/20mA/25mA (per input current) |
| Certifications | CE, ROHS | Wiring Method | Cable output (direct connection) |
| Operating Temperature | -25°C ~ +70°C | Insulation Material | ABS plastic housing |
| Mounting Direction | Horizontal/Vertical (free hanging) | Core Material | Ferrite |
| Dielectric Strength | Input/Output: AC 800V/1min, Output/Housing: AC 3.5KV/1min |
